12.8V 200ah Lithium Battery Lead Acid Replacement APP Control Solar Inverter Battery

Place of Origin China
Brand Name JHOTA
Certification shipping report
Model Number JHT-LFP12.8V200Ah
Minimum Order Quantity 1
Price Negotiable
Packaging Details Carton
Delivery Time 60 days
Payment Terms T/T
Supply Ability 1 piece, 10-14 days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Brand Name JHOTA Nominal Voltage 12.8V
Nominal Capacity 200Ah(customized) Impedance <35mΩ
Dimension 430*200*210mm Weight 27kg
Cycle Life 3000 Times Warranty 5 Years
Highlight

200ah Lithium Battery Lead Acid Replacement

,

12.8V Lithium Battery Lead Acid Replacement

,

APP Control Solar Inverter Battery

Leave a Message
Product Description
Specification
Nominal Voltage
12.8V
Nominal Capacity
200Ah@0.2C
Energy
2560Wh
Internal Resistance
<35mΩ
Cycle Life
3000 Cycles @0.2C Charging/Discharging,Until 70% Capacity
Self Discharge
<3.5% per month at 25℃
Max.Charging Voltage
14.0-14.6V
Charging Mode
At 0℃-45℃ temperature,charged to 14.6V at a constant current of 0.2C5A,and then,changed continuously with constant voltage of
14.6V until the current was not more than 0.02C5A
Charging Current
40A
Max.Charging Current
100A
Discharging Current
40A
Max.Continuous Current
100A
Max.Pulse Current
200A(<3S)
Discharging Cut-Off Voltage
10.0
Charge Temperature
0℃-45℃ @60±25% Relative Humidity
Discharge Temperature
-20℃-60℃ @60±25% Relative Humidity
Storge Temperature
0℃-45℃ @60±25% Relative Humidity
Water Dust Resistance
IP55
Cell&Format
IFR32700 N60,4S34P
Casing
Plastic
Dimension(L*W*H*Th)
430x200x210mm
Weight
Approx. 19.2kg
Terminal
M8
Product Description
12v 200ah Lifepo4 Battery For Household Energy Storage Replace Lead-Acid Battery

12.8V 200ah Lithium Battery Lead Acid Replacement APP Control Solar Inverter Battery 0



Quick details:

1.MOQ:1

2.Supply to all around the world

3.Best choice for off-grid solar, RV, marine, backup power system

4.Free of maintenance and provide 3 years warranty.

5.100% state of charge and 100% depth of discharge.

6.Vibration resistance of A-grade quality.



12.8V 200ah Lithium Battery Lead Acid Replacement APP Control Solar Inverter Battery 1



Description:

1. JHT-LFP12.8V200Ah is a 12V 200Ah deep-cycle lithium battery, using advanced LiFePO4 technology and M8 terminals.


2. The battery is designed for all deep-cycle applications, such as off-grid solar, RV, marine, camping, and backup power systems. This 12V 200Ah lithium iron phosphate battery can also be used to replace standard lead-acid batteries for electric scooters, UPS systems, fire alarm systems, access control systems and medical equipment. They are becoming more and more popular in military and aerospace applications. The 12V 200Ah lithium battery is very popular in the solar energy, RV and marine markets. They are commonly referred to as:
⑴ 12V RV lithium battery
⑵ 12V marine lithium battery
⑶ 12V solar lithium battery



3. Our high-power lithium iron phosphate batteries can withstand more than 3000 charge/discharge cycles. LiFePO4 batteries have the longest shelf life and can be stored for up to 2 years in any charged state without worrying about degradation. This makes them very suitable for seasonal equipment because they do not require long maintenance, such as your sailboat. This 12V 200Ah lithium battery can connect up to 4 batteries of the same type in parallel to form a 12V 400Ah, 12V 600Ah, or even a 12V 800Ah battery. It is also possible to connect up to 4 batteries of the same type in series to form 24V 200Ah, 36V 200Ah, or even 48V 200Ah batteries.





Precautions:

1. Keep battery away from children.

2. Do not drive a nail into the battery, strike it by hammer or tread it.

3. Do not give battery impact or fling it.

4. Do not put battery into microwave oven or high pressure container.

5. Do not use the battery with conspicuous damage or deformation.

6. Do not throw the battery into fire or heat it.
