16kwh 51.2v 314ah Battery Energy Storage System for Solar System

Place of Origin China
Brand Name JHOTA
Certification CE,UN38.3,MSDS
Model Number JHT-ESS51.2V314Ah
Minimum Order Quantity 1
Price Negotiable
Packaging Details Dangerous goods packaging wooden crates
Delivery Time 35days
Payment Terms T/T
Supply Ability 500pcs
Product Details
Brand Name JHOTA Battery Type LiFePO4
Installation In / Outdoor Cycle Life ≥7000 Times
Nominal Capacity 314Ah
Highlight

16kwh lithium storage battery

,

51.2v solar battery system

,

314ah home energy storage

Leave a Message
Product Description
Specification
Model
16kwh 51.2v 314ah Battery Energy Storage System for Solar System
BATTERY
Battery Type
LiFePO4
Battery Energy
16.08KWh
Battery Capacity
314Ah
16KWH Energy Storage System Net Weight
115 KG
16KWH Energy Storage System Net Dimension
825*415*235 mm
Battery Rated Voltage
51.2V (16S)
Overcharge Protection Voltage
58.4V
Overdischarge protection voltage
43.2V
Maximum Charging Current
150A
Maximum Discharging Current
150A
DOD
80%
Designed Life-span

 10 years

PV CHARGE
Product Description
16kwh 51.2v 314ah Battery Energy Storage System for Solar System

16kwh 51.2v 314ah Battery Energy Storage System for Solar System 0



Quick Details:

1. Warrenty: 7 Years
2. OEM/ODM: Accepatable
3. Cycle Life: >7000 times
4. The discharge rate: 0.5C-1C

5. Discharge temperature: -20-60℃
6. Charge temperature: 0-55℃

7. Design life:10 years

8. Storage temperature: -10-30℃



16kwh 51.2v 314ah Battery Energy Storage System for Solar System 1



Advantages:

1. Lower cost per use: The high-performance 16kWh battery reduces the cost per charge-discharge cycle by up to 20%, directly improving the system's economics.



2. Exceptionally long cycle life: High-quality lithium-ion batteries, especially those using lithium iron phosphate (LiFePO4) technology, generally have a cycle life of over 7,000 cycles, with some models even reaching 9,500 cycles. This means that you don't need to replace the battery for up to 10 years or more, significantly reducing the average annual cost.



3. A 16kWh energy storage system can store approximately 16 kWh of electricity (considering charging and discharging losses). This is typically enough to meet the basic electricity needs of a medium-sized family (such as a family of four or five) for a day and a night, and may even have enough capacity to replenish the power of an electric vehicle at night. If your home generates a lot of solar power during the day, or if there are frequent power outages in your area, this capacity can bring a very noticeable sense of "electricity freedom".



4. Powerful power output: The 16kWh battery not only stores power, but also discharges it. Its continuous output power is typically between 7kW and 10kW, with a peak power reaching up to 19kW. This is sufficient to simultaneously power multiple high-power appliances such as air conditioners, refrigerators, and water pumps, ensuring the whole family's comfort during power outages.



16kwh 51.2v 314ah Battery Energy Storage System for Solar System 2

Appliciation

- Whole house backup power
- Offline living and remote locations
- Self-consumption and electricity fee management
- Microgrids and community energy storage



Our Factory

16kwh 51.2v 314ah Battery Energy Storage System for Solar System 3
